Zhenjiang Leiluo Electronic Co., Ltd. is one of the leading manufacturers and suppliers of rf coaxial connector sma male solder for rg316 cable sma-s-jlmr316 in China. With a professional production team, we are able to meet the needs of the majority of our customers. Welcome to wholesale bulk premium products for sale here and get quotation from our factory. Also, customized service is available.
Introduction
This compact straight SMA male connector terminates RG316 coaxial cable.The sma male coaxial connector is designed for 50-ohm cable assemblies that require soldered connections.The connector mates RG316 cable runs with equipment having standard SMA female ports. Its small form fits installations with limited space, where connector dimensions and cable routing need consideration.
Features
The RG316 cable is prepared according to the specified stripping dimensions before assembly. The exposed center conductor is positioned at the connector contact and soldered in place.
The cable shielding layer is then connected to the SMA-S-JLMR316 connector body to maintain the coaxial structure. After the cable is positioned, the sma male coaxial connector is secured to complete the RF cable termination.
This method is suitable for RG316 assemblies where a solder connection is preferred over a crimp termination.
Specifications
|
Connector Type |
SMA-S-JLMR316 |
|
Cable Type |
LMR195 |
|
Impedance (Ohms) |
50 |
|
Frequency |
0~6GHZ |
|
Gender |
Male |
|
VSWR |
≤1.15 (0 ~ 3 GHz) |
|
Center Conductor |
Brass, Gold Plating |
|
Insulator |
PTFE |
|
Connector Body |
Brass, Nickel Plating |
|
Other Metal Components |
Brass, Nickel Plating |
|
Sealing Gasket |
Silicone Rubber |
Applications
The sma male coaxial connectors have been widely used in the following aspects:
- Communication and Network Equipment: Used for internal RF connections in 5G/6G base stations, Wi-Fi routers, wireless access points, WiMAX equipment and telecommunications terminals.
- Test and Measurement Instruments: Used for RF test ports and cable connections on network analyzers, spectrum analyzers, signal generators and related test equipment.
- Aerospace and Defense: Used in satellite communication systems, radar equipment, military navigation systems and electronic countermeasure equipment. The RG316 cable is suitable for applications with a typical operating temperature range of -55°C to over +150°C. The SMA connector uses a threaded coupling structure.
- Industrial and Automotive Electronics: Used for sensor signal connections in industrial robots, M2M communication modules, automotive radar systems and GPS positioning equipment.
